If you’re an avid watcher of the Marvel movies you’ll hear the term prototype used quite often, usually by Robert Downey Junior’s character: Tony Stark aka Iron Man.

The billionaire, playboy, philanthropist is always working on new suits, new weapon systems and other impressive (and far-fetched) technology like arc reactors, Quinjets and emergency response androids.

Iman Man MkII Prototype - Image courtesy of Marvel Entertainment

Back in the real world prototyping is actually a vital part in the life cycle of a project, particularly when dealing with the casting hundreds, if not thousands, of metal components that will form an integral part of a machine or device.

A prototype is essentially a draft version of the product/component that allows you to examine the feasibility of its production, identify errors or problems and correct them before the time and financial commitment is made in producing the finished article.

Why Prototype?

It may seem, on the surface at least, that your design is robust and perfectly suitable for production. That’s fine. Some designers know their craft and are supremely confident in their abilities.

However it’s better to fail early generally speaking because it costs a lot less, it’s also far more private. Factory recalls cause no end of harm to a company’s reputation, not to mention the damage it does to the bottom line.

Prototyping allows you to quickly identify the areas that work on paper but don’t work in practice.

But prototyping doesn’t just allow you to identify problems with the design: whether it’s warping, flaws, unexpected failure points; it allows you to test for fit and function.

Whilst the design may be sound in isolation, changes elsewhere in the overall design could render the item useless. This is not something you would want to discover once the expensive process of hard tooling has begun. Essentially, it mitigates risk.

Prototyping also allows you to identify refinements that can be made which will enhance the product, a better way of casting for a high quality result and efficiencies in the design which will make it cheaper and easier to cast.

Finally, prototyping also throws up the unexpected like the errors that no one foresaw beyond the component itself. Issues like how the component will fit or will the proposed assembly process work can all examined with a working prototype.

It Builds Confidence

Investing in a product or component is a commitment in time but also of money and any capital expenditure into tooling and production needs to be backed by supreme confidence that it will not just work but work consistently for days, months or years before they are replaced.

Prototyping gives the business that confidence to make an informed decision about whether or not that item or product is up to the task or if it needs to go back for redesign.

The important thing to recognise is that we’re only human. Mistakes get made. Some are minor some are major but when a component can only have a few microns tolerance, a mistake could render it useless.

For a designer, the goal is to make a product that is not only fit for purpose, but also to design the product so that it can be manufactured as easily and as cost effectively as possible.

Producing a prototype allows the designer and project engineers to review best practice techniques such as Design for Manufacture (DFM), Design for Assembly (DFA), and provides the opportunity to carry out tests for Failure Modes and Effects Analysis (FMEA).

This diligence gives businesses the information they need to progress with a project confident in the knowledge that the components are all fit for purpose and that investment will see a fully functional, market ready product.

MRT Castings are a full service casting and finishing specialist with over 70 years of experience. Our engineering team enjoy working with customers to develop their component concepts into cast or machined component designs ready for production.

We offer a full range of prototyping options, from simple nylon 3D prints right through to sand cast or machined from solid full-function samples, ready for testing, before you commit to diecasting tooling. If you would like more information on how we can support you on your design and casting needs contact us today.
